When you launch the VeeaHub Manager (VHM) app, it opens to the Manage tab by default. This tab provides an overview of your account’s mesh networks and displays how many VeeaHubs are enrolled in each mesh.

From here, you can add new VeeaHubs to an existing mesh, create new meshes, or tap into individual VeeaHubs to view and manage their configuration and status.

Adding a VeeaHub

Add a VeeaHub to an existing mesh

To add a new VeeaHub to an existing mesh:

1. On the Manage tab, tap + Add VeeaHub
2. Follow the on-screen prompts, including scanning the QR code on the bottom of the unit
3. When prompted on the Select Mesh screen, choose the mesh you’d like to add the VeeaHub to from the list

The new VeeaHub will join the selected mesh and automatically download its configuration.

Create a new mesh

To create a new mesh with a VeeaHub:

1. On the Manage tab, tap + Add VeeaHub
2. Follow the prompts and scan the QR code on the VeeaHub
3. On the Select Mesh screen, tap + Create a new mesh
4. Accept the default mesh name or tap it to rename
5. Configure your Access Point (Wi-Fi) settings or choose to skip this step and set it up later
6. Tap Continue to complete the setup process

The VeeaHub will now be enrolled as the Gateway for the new mesh.

Managing VeeaHubs

To manage a VeeaHub:

1. From the Manage tab, tap the mesh containing the VeeaHub
2. Tap the VeeaHub you want to configure
3. You’ll be taken to the Dashboard, which provides quick access to available settings and management options

The available options may vary depending on the model and configuration of the selected VeeaHub. These include network settings, access point management, service status, software updates, and more.

For detailed guidance on each available option, refer to the rest of the articles in this section.
